Fiber Plastic Geogrid
Fiber Plastic Geogrid
Ruimin’s crawler excavator is engineered for high-performance in construction and mining operations. Equipped with a robust hydraulic system, it delivers exceptional digging force and fuel efficiency, cutting operational costs. Built with heavy-duty ISO 9001-certified components, it ensures long-lasting durability in harsh environments. Backed by 15+ years of expertise, we offer customizable configurations and reliable worldwide after-sales support to meet your project needs.
Advanced Subgrade Reinforcement Technology
Providing exceptional soil interlock and load distribution for large-scale civil engineering and foundation stability.
Mechanical Interlock & Friction
The extruded coarse surface creates superior friction within the soil matrix.
- Stress Resistance: High-tenacity fibers withstand massive fill soil pressure.
- Shear Limitation: Effectively restricts lateral soil extrusion and foundation uplift.
- Stability: Maintains aggregate position under dynamic and static loads.
Load Diffusion Efficiency
Engineered to transform vertical foundation loads into a uniform distribution.
- Reinforced Cushion: High stiffness promotes uniform transmission to soft soil layers.
- Bearing Capacity: Dramatically improves the load-bearing potential of weak foundations.
- Stiffness Optimization: Increases the overall rigidity of the compression layer.
Settlement & Deformation Control
Critical for adjusting and managing foundation deformation over long-term use.
- Non-Uniform Settlement: Minimizes risks of differential settlement in complex terrains.
- Structural Longevity: Preserves the integrity of the upper infrastructure.
- Strain Management: High tensile strength at low elongation (2% and 5% strain).
Seismic Energy Absorption
A flexible composite structure designed for resilience in earthquake-prone zones.
- Energy Dissipation: Absorbs and disperses seismic energy through the flexible grid matrix.
- Ductility: Retains structural bond even under significant ground vibration.
- Safety Assurance: Proven performance in seismic hazard mitigation for foundations.
Technical Specifications: RMXS TGSG Series High-Strength Geogrid
| Specification Item | TGSG 50-50 | TGSG 100-100 | TGSG 150-150 | TGSG 200-200 |
|---|---|---|---|---|
| Material | High-Tenacity Warp-Knitted Polyester Fiber | |||
| Dimensions (Width/Length) | Width: 2m, 4m, 6m | Length: Customizable to Project Scale | |||
| Aperture Size (mm) | Approx. 65 x 65 mm (Regular Coarse Pattern) | |||
| Available Colors | Black (Standard), Blue, Green, or Customized | |||
| Ultimate Tensile Strength (kN/m) Longitudinal & Transverse |
≥ 50 | ≥ 100 | ≥ 150 | ≥ 200 |
| Elongation at Nominal Strength (%) | ≤ 16% | |||
| Tensile Strength @ 2% Strain (kN/m) | ≥ 17 | ≥ 35 | ≥ 52 | ≥ 69 |
| Tensile Strength @ 5% Strain (kN/m) | ≥ 34 | ≥ 70 | ≥ 104 | ≥ 138 |
